16.07kWh LiFePO4 Battery Floor Mounting IP20 7000 Cycles Designer White Body

SKU: 12765 | VT: VT-48290
12765n
12765-2
12765-3
12765-4
12765-5
12765-6

Downloads
Manual
IEC 62619
Warranty Conditions
Technical Specifications
CEI 0-21
||
PPWR Declaration of Conformity
Declaration of Conformity
CE
Specifications
General Information
Electrical Data
Wattage
16.07kWh
Current
  • Recommended Charge Current: 140A
  • Max. Charge/Discharge Current: 150A
Voltage
  • Nominal Voltage: 51.2V
  • Float Charge Voltage: 57.6V
  • Discharge Cut-off Voltage: 43.2V
Body Details
Mount
Floor Mounting
Capabilities
IP Rating
IP20
Battery Capacity
314 Ah
Cells Chemistry
LiFePO4
On/Off cycles
>7000
Working conditions
  • Charge temperature Range (°C): 0-60
  • Discharge temperature Range (°C) -20 +60
  • Storage Temperature Range(°C): 15-35
  • Working Temperature Range(°C): 0-60
Dimensions
Size
690H x 630 x 240 mm
Product Data
Order code
12765
Product code
VT-48290
Items per box
1
Additional
Release Date
18.09.26
Brand
V-TAC
Additional information
Communication with Inverter: CAN
Warranty
10 years
