10kW Three Phase Hybrid Solar Inverter Black Body

SKU: 12307 | VT: SUN-10K-SG04LP3-EU
12307-2
Installing a Three Phase Hybrid Inverter Deye V-TAC

Downloads
Manual
CEI 0-21
||||
Declaration of Conformity
Warranty Conditions
|
Declaration of product model
Technical Specifications
EMC License
|
LVD License
||||
Specifications
General Information
Electrical Data
Wattage
  • Max. DC Input Power: 13000W;
  • Rated AC Output and UPS Power: 10000W;
  • Max. AC Output Power: 11000W;
Current
  • AC Output Rated Current: 15.2/14.5A;
  • Max. AC Current: 22.7/21.7A;
  • Max. Continuous AC Passthrough: 40A;
Voltage
  • Rated PV Input Voltage: 550V (160V～800V;
  • Start-up Voltage: 160V;
  • MPPT Voltage Range: 200-650V;
  • Full Load DC Voltage Range: 350-650V ;
Frequency
50/60Hz
Power Factor
0.8 leading to 0.8 lagging
Phase
Three Phase
Capabilities
Working conditions
`-40~60°C, >45°C derating
IP Rating
IP65
Dimensions
Size
422W x 699.3H x 279D
Product Data
Order code
12307
Product code
SUN-10K-SG04LP3-EU
Item Weight
48 kg
Additional
Release Date
07.05.25
Warranty
10 years
Brand
Deye
