18kW Hybrid Solar Inverter Single Phase 230VAC 10yrs Warranty

SKU: 12780 | VT: SUN-18K-SG01LP1-EU-AM3-P
12780-2
12780-3
12780-4

Downloads
Manual
IEC 63027
EN 50549
Technical Specifications
EMC License
LVD License
|
Specifications
General Information
Electrical Data
Current
  • Max. Operating PV Input Current (A): 36+36+36;
  • Max. Input Short-Circuit Current (A): 54+54+54;
  • Rated AC Input/Output Current (A): 81.9/78.3;
  • Max. AC Input/Output Current (A):90/86.1
  • Max. Continuous AC Passthrough: 200A;
Wattage
  • Max. PV Input Power (W): 28800;
  • Max. PV Access Power (W): 36000;
  • Rated AC Input/Output Active Power: 18000;
  • Max. AC Input/Output Apparent Power (VA) 19800;
  • Peak Power (off-grid) (W): 2 times of rated power, 10s
Phase
Single Phase
Voltage
  • Rated PV Input Voltage: 370V;
  • MPPT Range: 150-425V;
  • Start-up Voltage: 370V;
Frequency
Rated Input/Output Grid Frequency/Range(Hz) 50/45-55, 60/55-65
Power Factor
0.8 leading to 0.8 lagging
Capabilities
IP Rating
IP65
Working conditions
-40 to +60℃, >45℃ Derating
Dimensions
Size
464 x 863 x 282 mm
Product Data
Order code
12780
Product code
SUN-18K-SG01LP1-EU-AM3-P
Item Weight
54.1 kg
Items per box
1
Additional
Release Date
04.09.26
Brand
Deye
Additional information
Noise (dB) <55
Warranty
10 years
